2J5410HP
380-470 MHz Tetra High Gain Customizable Antenna
Connections (1)
1×
TETRA / UHF / LMR - 380-470 MHz
| Mounting | Adhesive Mount, Wall Mount, Wall/Adhesive Mount |
|---|---|
| Dimensions (mm) | 60 × 112.5 × 11.3 |
| Operating temperature | -40 °C to +85 °C |
| Standard colors |
Black
White
|
Global Delivery
Ready to Ship
EU Quality
Loading...
Antenna and electrical specifications
connection 1
TETRA / UHF / LMR - 380-470 MHz
| Standards | TETRA |
|---|---|
| Frequency | 380-470 |
| VSWR | ~2:1 |
| Efficiency (%) | ~45 |
| Peak Gain (dBi) | ~2.8 |
| Impedance (Ohm) | 50 |
| Polarisation | Linear |
| Max. Input Power (W) | 50 |
Antenna Description
Key Features
Ground Plane Independent
Customizable Cable and Connector
Low Profile
High Gain
Public safety TETRA Antenna
2.8 dBi TETRA Peak Gain
Applications
Security & Safety
Defense & Public Safety
