Antenna and electrical specifications
connection 1
2.4 / 5.0 / 6.0 GHz Tri-Band WIFI 6E / WIFI 7
| Frequency | 2410-2490, 4920-5925, 5925-7125 |
|---|---|
| VSWR | ~1.5:1, ~2.7:1, ~3.7:1 |
| Standards | WiFi, BT, ZigBee, ISM, SigFox, LoRa |
| Efficiency (%) | ~54.4, ~48.7, ~45.5 |
| Peak Gain (dBi) | ~1.7, ~5.1, ~4.6 |
| Impedance (Ohm) | 50 |
| Polarisation | Linear |
| Max. Input Power (W) | 10 |
