Antenna and electrical specifications
connection 1
2.4/5.0 GHz ISM
| Standards | WiFi, BT, ZigBee, ISM |
|---|---|
| Frequency | 2410-2490, 4920-5925 |
| VSWR | ~2.1:1, ~2.8:1 |
| Efficiency (%) | ~35, ~60 |
| Peak Gain (dBi) | ~1.4, ~3.2 |
| Impedance (Ohm) | 50 |
| Polarisation | Linear |
| Max. Input Power (W) | 25 |
