Antenna and electrical specifications
CELLULAR
Standards | 2G and 3G |
---|---|
Frequency | 824-960, 1710-2170 |
VSWR | ~1.4:1, ~1.5:1 |
Efficiency (%) | ~39, ~26 |
Peak Gain (dBi) | ~0.7, ~0.2 |
Impedance (Ohm) | 50 |
Polarisation | Linear |
Max. Input Power (W) | 50 |
Standards | 2G and 3G |
---|---|
Frequency | 824-960, 1710-2170 |
VSWR | ~1.4:1, ~1.5:1 |
Efficiency (%) | ~39, ~26 |
Peak Gain (dBi) | ~0.7, ~0.2 |
Impedance (Ohm) | 50 |
Polarisation | Linear |
Max. Input Power (W) | 50 |
